Product Description – 2-Post Electric Lift 4.0 t with Drive-Over Ramp
Professional Line – Model: DTPF 6093 EP
NEW: ANTI-LIFT-UP Technology
This innovative system allows effortless replacement of the timing belt, gearbox and motor removal without the usual need to lift the vehicle before lowering the lift.
New: Practical Storage Trays
The trays can be hooked into the lift arms and are ideal for storing small parts, screws and tools.
Optimized Maintenance System
The DTPF 6093 EP features a special mechanism that allows significantly faster replacement of worn guide sliders without removing the lifting carriages from the columns.
Enhanced Safety
In addition to standard safety features, the lift includes a secondary lower limit switch to prevent accidental foot injuries.
Ideal for Tire Services, Workshops and Hobby Mechanics
Suitable for cars, SUVs and small vans. Very popular among professional workshops and private users with a wide range of vehicle types.
Included in Delivery
- 4 height-adjustable lifting pads
- 1 upper limit switch
- 1 lower limit switch (foot safety)
- 4 solid rubber pads
- 4 van adapters (85 mm)
- 2 cylinder protection covers
- 10 heavy-duty anchors (180 x 20 mm)
- 4 tool trays for lift arms
Construction Advantages
Inside-mounted lift arms
Provide higher load capacity and improved structural stability.
Door-friendly recessed bolts
Allow wide door opening without hitting or damaging the vehicle doors.
Easy Service Structure
Guide sliders can be replaced even while the lift remains fully assembled.
Premium Sliding Blocks
Available in multiple sizes to ensure minimal play, reduced wear and long service life.
Dual Hydraulic System
Two powerful hydraulic cylinders ensure smooth and even lifting and lowering.
Safety Features
- Upper limit switch
- Lower limit switch
- Automatic safety locks
- Automatic arm release
- Emergency lowering function in case of power failure
Features at a Glance
- Fully electric system
- Drive-over ramp (approx. 40 mm)
- 2- and 3-section telescopic arms
- Upper and lower limit switches
- 4 lifting pads with rubber blocks
- 4 van adapters
- 10 heavy-duty floor anchors
- 2 cylinder covers
- 2 hydraulic cylinders
- Control box with emergency stop
- Synchronization via equalizing cables
- Automatic safety locks
- Automatic arm release
- Automatic stop at maximum height
- Emergency-lowering function
- German user manual
- Lift inspection book
- CE certificate (TÜV)
- Powder-coated (DIN 55633)
- Manufactured according to ISO 9001
- 24-month warranty
- Excellent spare parts availability
Technical Specifications
| Max. lifting capacity |
4000 kg |
| Max. lifting height |
1900 mm (2080 mm with adapters) |
| Min. pad height |
80 mm / 115 mm |
| Max. drive-through width |
2440 mm |
| Lifting / lowering time |
50 s / 30 s |
| Quick-lowering |
20 s |
| Total width |
3310 mm |
| Total height |
2814 mm |
| 2-section arms |
900 / 1450 mm |
| 3-section arms |
700 / 1400 mm |
| Power connection |
400 V / 50 Hz or 230 V / 50 Hz |
| Motor power |
2.2 kW / 16 A |
| Noise level |
75 dB |
| Hydraulic oil |
optional |
| Net weight |
600 kg |
| Packaging size |
2850 x 800 x 730 mm |
| Shipping weight |
630 kg |
Manual Download
Operating Manual: DTPF 6093 EP
